Technics - SL-1500CS Direct Drive Turntable

The SL-1500C with Technics’ Delta Sigma Drive motor control borrowed down from their digital amplifiers, and a metallic grey finish you cannot get on the standard model.

The CS is not a colour variant and it is not a cartridge bundle. Technics’ own press release calls it “a superior, upgraded model of the award-winning SL-1500C,” and the named difference is the motor control electronics.

ΔΣ-Drive — Delta Sigma Drive — takes the one-bit signal-processing technique Technics developed for its full-digital amplifiers and applies it to generating the sine wave that drives the platter motor. The claim is that a smoother, more precisely shaped drive waveform means less motor vibration reaching the record, and Technics describes the goal as “eliminating motor vibrations down to the very limits of measurable.” It first appeared on the SL-1200GR2 and has since worked its way down the range to this model.

Everything else Technics describes as “largely inherited” from the SL-1500C: the same aluminium die-cast chassis, the same 332mm two-layer platter, the same static-balance tonearm with 0 to 6mm of height adjustment, the same built-in phono equaliser with separate PHONO and LINE outputs, the same Auto Lifter, and the same factory-fitted Ortofon 2M Red. The finish is new — a metallic grey not offered on the standard SL-1500C.

One thing Technics does publish for the CS that it does not publish for the plain C: the tonearm offset angle, 22°. And one thing we could not find at all: an SL-1500CS-specific owner’s manual. Several figures the SL-1500C manual gives — the phono stage’s exact gain, the cartridge’s output and mass — have no published CS equivalent. They are almost certainly the same. We are not going to print them as though Technics said so.

Features

• ΔΣ-Drive Delta Sigma motor control, derived from Technics’ full-digital amplifier technology
• Metallic grey finish, unique to this model
• Ortofon 2M Red moving-magnet cartridge fitted and aligned at the factory
• Built-in phono equaliser with separate PHONO and LINE outputs
• Auto Lifter raises the tonearm at the end of the side
• 332mm aluminium die-cast platter, approximately 2kg
• Static-balance tonearm on gimbal suspension with a machined housing, 0–6mm height adjustment
• 33 1/3, 45 and 78rpm

Specifications

• Type: Direct drive manual turntable with Auto Lifter
• Drive: Direct drive with ΔΣ-Drive (Delta Sigma Drive) motor control
• What ΔΣ-Drive does: Technics applies one-bit signal processing from its full-digital amplifiers to optimise the motor drive sine wave, with the stated aim of reducing motor vibration to the limits of measurement. It was introduced on the SL-1200GR2
• Motor: Brushless DC motor. Coil and pole counts are not published
• Platter: Aluminium die-cast, 332mm, approximately 2.0kg including the turntable mat
• Speeds: 33 1/3, 45 and 78rpm. Technics footnotes the 78rpm setting on this model without publishing the footnote text; on the SL-50C the equivalent footnote resolves to an actual speed of 78.26rpm
• Starting torque: 0.18N·m (1.8kgf·cm)
• Start-up time: 0.7 seconds from standstill to 33 1/3rpm
• Wow and flutter: 0.025% W.R.M.S. No measurement standard is named
• Rumble / signal-to-noise ratio: Not published
• Tonearm: Static balance. Technics’ UK page describes gimbal suspension construction with a machined housing and a high-precision bearing
• Effective tonearm length: 230mm
• Overhang: 15mm
• Offset angle: 22°
• Effective tonearm mass: Not published. Technics publishes no tonearm effective mass figure for any turntable in the current range.
• Arm height adjustment: 0–6mm
• Anti-skate: An anti-skating control dial is fitted and is set to match the stylus pressure. Technics does not publish what mechanism drives it — spring, magnet or thread-and-weight — on the product page or in the manual, so we are not going to guess.
• Headshell: Included, approximately 7.6g
• Cartridge weight range: 5.6–12.0g without the auxiliary weight; 14.3–20.7g including the headshell. Note that Technics frames this range differently on the SL-1500C’s page and does not explain the difference
• Cartridge fitted: Ortofon 2M Red, moving-magnet
• Cartridge specification: Not published for this model. No SL-1500CS-specific owner’s manual could be located, so the output, tracking force and mass figures the SL-1500C manual carries have no confirmed CS equivalent
• Built-in phono equaliser: Yes, inherited from the SL-1500C per Technics’ press release. The exact gain figure is not published for this model — the SL-1500C’s is 37dB, but we have no Technics document stating it carries over
• Auto lift: Auto Lifter, inherited from the SL-1500C. Raises the cartridge at the end of the record
• Outputs: PHONO (pin jack) x1, LINE (pin jack) x1, earth terminal x1
• Insulators: High-damping insulator using a spring and rubber
• Dimensions: 453 x 169 x 372 mm (W x H x D)
• Weight: Approximately 9.9kg (21.9 lbs)
• Power supply: AC 120V, 60Hz in the US; AC 110–240V, 50/60Hz globally
• Power consumption: 8.0W on; approximately 0.2W off
• Country of manufacture: Not published. Technics prints no country-of-manufacture statement on its product pages, specification sheets or owner’s manuals for any model in the current range — we checked all three for this product. Claims circulate online about where Technics builds its turntables; none of them come from Technics, so we are not going to repeat them here as fact.
• Warranty: Panasonic administers Technics warranty in the United States and the term varies by model rather than by product category. The SL-1500CS does not yet appear in Technics’ published US warranty table. The SL-1500C it is derived from is listed at two years parts and labour. Ask us before you buy if the term matters and we will confirm it with Panasonic rather than assume. Technics states that product registration is not required and does not extend coverage. A dated sales receipt is required, coverage runs to the original purchaser, and the product must be purchased and serviced in the United States. Non-rechargeable batteries, antennas and cosmetic cabinet parts are excluded. Note that Technics’ warranty statement does not explicitly name styli or cartridges as excluded items, even though wear-part exclusion is normal industry practice — we would not assume coverage either way without asking Panasonic first.
